Review:
Neo Coolcam Door sensor
Frequently Asked Questions:
What do the colors of the LED mean?
| Red | LED is on for 1 sec | Not added to network |
| 1x flashing | Door/window open | |
| Quick Flash | Cover Removed | |
| Purple | More than 2 sec. | Hold and press for 10 sec, off after 12 sec. |
| Green | 1 sec. after power on | Already added to network |
| 1x flashing | Door/window closed | |
| White | 2 sec. on | Hold and press 5 sec, off after 7 sec. |
| Cyan | Quick Flash | Cover Close |
| Blue | Blink (1 sec interval) | Added to network |
| Blink (500 ms. interval) | Removed from network | |
| Yellow | Blink (500 ms. interval) | OTA update |
| Always on | Press button for 12 sec. |
Can I turn off the LED?
Yes, that is possible via the parameters. See here.
What kind of USB power supply do I need?
You can use a standard 1.5/1A USB adapter.
What is the maximum distance between the sensor and the magnet?
Make sure they are no more than 2 cm apart.
What kind of battery is in Neo Coolcam by sensor?
A CR123A battery.
What are the dimensions of the Neo Coolcam door sensor?
82x27x23mm for the sensor and 50x13x16mm for the magnet
