RobbSmarrt Rotary dimmer Z-Wave 2-wire

Parameters:

With parameters you can change things like the sensor itself, such as the update time and sensitivity of the motion sensor. Most controllers have this baked in by default.

2) Memorize status after power failure
Default setting: 2
Available setting: 0 (Turn off), 1 (Turn on), 2 (Remember power status before power failure)

4) Standard fade time
Default settings: 1
Available settings: 0 sec -127 sec

5) Minimum dim level:
Default settings: 15
Available settings: 0 (Low) - 50 (High)

6) Maximum dimming level:
Default settings: 100
Available settings: 0 (Low) - 100 (High)

7) MOSFET driver type:
Default settings: 0
Available Settings: 0 (Trailing Edge) - 1 (Leading Edge)

8) Dim steps button:
Default settings: 5
Available settings: 1 - 50

9) Rest via external switch
Default settings: 1
Available settings: 0 (on 1.5 sec> press 3x) - 1 (off)

13) Overload protection
Default setting: 200
Available setting: 1 - 200 (W), 0 (not active)

14) Flow threshold reporting
Setting to determine at how much change of the energy level (W) a report must be sent to the controller.
Default setting: 10 (Off)
Available setting: 1 - 255 (W)

15) Flow level reporting
Setting to determine at how much change (%) of the energy level a report must be sent to the controller.
Default setting: 20 (Off)
Available setting: 1 - 100 (Percentage)

21) Flow reporting
Default setting: 600 (10 min)
Available setting: 0 (Off), 5> 2678400

22) Energy reporting
Default setting: 1800 (30 min)
Available setting: 0 (Off), 5> 2678400

23) Voltage reporting
Default setting: 0 (off)
Available setting: 0 (Off), 5> 2678400

24) Current reporting
Default setting: 0 (off)
Available setting: 0 (Off), 5> 2678400

31) Dim curve
Default setting: 0 (linear)
Available setting: 0 (linear), 1 (logaritmic)

32) Start dim level
Default setting: 0 (0)
Available setting: 0 (Low), 99 (High)
